Vsmile Milling Burs Amann Girrbach ® Compatible

Best fit at the highest possible surface quality



In order to achieve maximum economical use, the tools are consistently checked for service life and optimised within the system as part of the newly developed intelligent milling and grinding strategies.



Compatible With Amann Girllbach For Zirconia / PMMA / Wax Milling
Shank Dia.(mm)	3.0	3.0	3.0	3.0
Head Dia.(mm)	2.5	1.0	0.6	0.3
Overlength(mm)	47	47	47	47
Coating	Diamond/Diamond Liked/Uncoated/Rainbow
Compatible With Amann Girllbach For Emax / Glass Ceramic / Lithium Disilicate Grinding
Shank Dia.(mm)	3.0	3.0	3.0	3.0
Head Dia.(mm)	1.8	1.4	1.0	0.5
Overlength(mm)	43	43	43	43

Amann Girrbach CAD/CAM Dental Milling Bur

Model:
Ceramill mikro 4x
Ceramill mikro 5x
Ceramill mikro ic 4x
Ceramil motion2 5x
Ceramil matik 5x

Material: Tungsten Steel
Coating: CVD Diamond Coating / PVD Diamond Coating / Diamond Liked Coating / Professional Coating for Emax grinding
Packaging: Individually packing

Your Benefits
High quality of restorations and fit due to precisely manufactured tools
Highest level of process safety due to matched and validated milling and grinding strategies
Minimal wear of milling cutters at optimal milling speeds



Dental Milling Tools For Processing Various Materials

Our tool specialists have developed optimal cutting-edge geometries for machining the various materials used in dental technology, from wax to cobalt-chrome. The result is a perfect balance between the best possible surface quality of the material to be machined and the longest possible service life of the milling tool.
