Vsmile Definite Dental Zirconia Sintering Furnace
Vsmile Definite Dental Zirconia Sintering Furnace

Definite - Sintering furnace | |||
Chamber size | Dia100xH100mm | Definite is specially designed for the sintering of small batch samples of zirconia denture crystal, structural ceramics, and polymer ceramics. Automatic program for heating, platform moving. It’s very convenient for dental crown firing. The rated power is only 2kW, which is suitable for any small lab. High speed temperature increasing, 0-40℃/min. 7 inch HD touch screen, easy to operate, can store 30 different processes, programs. | |
Max. temperature | 1700 ℃ (<2hour) | ||
Working temperature | 800-1600℃ | ||
Temperature controlling | PID automatic control via SCR (Silicon Controlled Rectifier) power control with phase angle fired, current limiting resistor. | ||
Touch screen panel which can store 30pcs different programs | |||
Built in PID Auto-Tune function with overheating & broken thermocouple broken protection. | |||
Over temperature protection and alarm allows for operation without attendant. | |||
Temperature accuracy | ± 1℃ | ||
Temperature uniformity | ± 5℃ | ||
Heating rate | 0-30℃ /min | ||
Outer dimension | 550X420X810mm | ||
Working voltage | 220V, 50HZ/60HZ, 1 phases (As per your order) | ||
Rated power | 2KW | ||
Net weight | 90kgs | ||
Gross weight | 110kgs |
